Outdoor LED Displays

P2.5–P16 pitch. IP65/IP68 waterproof rating. Up to 8,000 nits for direct sunlight visibility. For facades, billboards and sports venues.

Outdoor · DOOH · Billboards · Stadiums

Outdoor LED Displays

Outdoor LED display technology has advanced dramatically — modern P2.5 cabinets deliver close-range image quality previously only achievable indoors, while P16 modules scale to stadium-sized installations visible from hundreds of metres. All products in this range are IP65 or IP68 rated, built with corrosion-resistant aluminium die-cast cabinets and rated for continuous 24/7 operation in ambient temperatures from -40°C to +60°C. Auto-brightness adjustment responds to ambient light conditions to ensure visibility in direct sunlight without wasting power at night.

CE RoHS FCC

Technical Specifications

Pixel Pitch RangeP2.5 / P4 / P5 / P6 / P8 / P10 / P16
Peak BrightnessUp to 8,000 nits
IP RatingIP65 (front) / IP68 (fully sealed)
Cabinet MaterialAluminium die-cast, powder coated
Operating Temp.-40°C to +60°C
Auto BrightnessYes — light sensor driven
Wind LoadUp to 130 km/h (structure dependent)
Refresh Rate1,920–3,840 Hz
CertificationsCE, RoHS, FCC, SASO, ESMA available
ApplicationsFacade, billboard, DOOH, stadium perimeter, road signage

Source Outdoor LED Displays

Tell us your screen dimensions, quantity, installation environment and target market. We'll send a competitive sourcing proposal within 24 hours.
